XDB1002-11 is an industrial-grade general-purpose particle concentration transmitter. It adopts the principle of laser scattering measurement and uses a unique dual-frequency data acquisition technology to screen and obtain the number of particles of equivalent particle size per unit volume. It also uses a scientific and unique algorithm to calculate the mass concentration of particles of equivalent particle size per unit volume, and outputs data via the 485 interface and ModBus-RTU protocol. It can be used in outdoor weather stations, dust monitoring, libraries, archives, industrial plants and other places that require PM2.5 or PM10 concentration monitoring.
1.Range: 0-1000ug/m3, resolution 1ug/m3
2.PM2.5, PM10, PM1.0 output simultaneously
3.Unique dual-frequency data acquisition and automatic calibration technology, consistency can reach ±10%
4.Adopt advanced laser anti-attenuation technology to ensure long-term stability of equipment
5.Standard ModBus-RTU communication protocol, easy access
|
Line color |
Description |
 |
|
|
Power supply |
Brown |
Supply+ |
|
|
Black |
Supply- |
||
|
communication |
Yellow |
485-A |
|
|
Blue |
485-B |
